Features
Exceptionally high power rating - up to 50% more than standard Belts
Special cog design facilitates enhanced flexibility and quicker heat dissipation
High transmission efficiency up to 98%, providing optimum output
Maintenance-free property of the Belt ensures less machine downtime and an extended service life
Complies with ISO 1813 - for anti-static property
Space saving potential
REACH & RoHS compliant provides an eco-friendly system
Smooth operation with a minimum tension-drop
Temperature range from -35°C to +130°C

Constructional Details
High strength, maintenance free, premium cord for lower belt elongation
Fiber reinforced EPDM base compound offers excellent heat resistance and minimizes abrasion for longer service life
Specially Engineered cog design enhanced belt flexibility and accelerated heat dissipation rate

Parameter Name	Parameter Value
Type	toothed V
Material	EPDM
Product applications	for heavy-duty applications for presses for generator sets fan for hot rolling mills
Sector	for the textile industry
Other characteristics	high-performance anti-static high-power raw edge high wear resistance maintenance-free friction high temperature-resistant abrasion-resistant
Length (mm)	546 - 5000
Width (mm)	9.7 - 15.8
Thickness	8 mm, 10 mm, 13.5 mm, 14 mm, 18 mm (0.31 in)
Temperature	Max.: 130 °C (266 °F)Min.: -35 °C (-31 °F)
