Features
- Superior service life ensuring a higher return on investment.
- Extended temperature range from -50°C to +130°C for optimal performance in diverse applications.
- Maintenance-free performance resulting in minimal service costs.
- Exceptionally high power rating over standard Belts.
- Special Belt surface design for superior flexibility and abrasion resistance.
- High transmission efficiency up to 98%, resulting in enhanced productivity and reduced cost of ownership.
- Special cog design for enhanced flexibility and rapid heat dissipation for improved product performance and operational life.
- Complies with ISO 1813 for anti-static properties for enhanced operational safety.
- Space-saving potential to allow for compactness in the drive.
- REACH and RoHS compliant, enabling a sustainable ecosystem.

Constructional Details
1.Specially designed rubber top to provide excellent flexibility and to resist abrasion loss.
2.Specially design EPDM Compound with extreme bonding for superior life.
3.High strength, maintenance-free, EPDM polyester cord for negligible elongation.
4.Special design fibre-loaded EPDM compound for superior power transmission.
5.Specially Engineered cog design with stretchable fabric to enhanced Belt flexibility, crack resistance and accelerated heat dissipation rate.

Parameter Name	Parameter Value
Type	toothed V
Material	rubber
Product applications	for heavy-duty applications
Other characteristics	maintenance-free high-performance anti-static raw edge high-power abrasion-resistant high-resistance
Length (mm)	700 - 5000
Width (mm)	9.7 - 22
Thickness	8 mm, 10 mm, 14 mm, 18 mm (0.31 in)
Temperature	Min.: -50 °C (-58 °F)Max.: 130 °C (266 °F)
