● USB3.0 interface, 5Gbps theoretical transfer bandwidth, power supply via USB interface；
● Compact size of 29mmx29mmx29mm;
● 128MB on-board cache for data transmission or image resend;
● Support Software Trigger/Hardware Trigger/Free Run Mode;
● Support ISP functions including Sharpness/Denoising/Gamma/LUT/BlackLevel Correction/TargetBrightness etc.;
● Color cameras support interpolation, white balance, chroma, saturation, etc.；
● Support multiple image data formats output/ROI/Mirror, etc.；
● Compatible with USB3.0 Vision protocol and GenICam standard;
● Comform to CE, FCC, RoHS;

● Gigabit Ethernet interface, providing 1Gbps bandwidth with a maximum transmission distance of 100m;
● 256MB on-board cache for data transmission or image resend;
● Support Software Trigger/Hardware Trigger/Free Run Mode;
● Support ISP functions including/Gamma/LUT/BlackLevel Correction/TargetBrightness/Contrast etc.;
● Color cameras support interpolation, white balance, color conversion matrix, chroma, saturation, etc.;
● Support multiple image data formats output/ROI/Mirror, etc.;
● Conform to GigE Vision V2.0 protocol and GenICam standard;
● Support PoE power supply, DC 9V~24V wide voltage power supply;

Parameter Name	Parameter Value
Applications	machine vision
Technology	digital
Function	image processing
Spectrum	full-color, monochrome
Sensor	CMOS
Interface	PoE GigE USB 3.0
Resolution level	1280 x 1024
Resolution	1.3 Mpx
Other characteristics	with global shutter board compact
