WLINK G530 is the Industrial 5G router upgraded from the classic G510 LTE router, equipped with ruggedized enclosure, powerful internal components to handle temperature extremes, dust and moisture and terminal block for secure power supply. It features 4x100/1000M ethernet port, RS-232/485 serial port, DI/DO port, as well as Redundant SIM slots. Ideal for harsh environments, WLINK G530 5G router provide the rugged, reliable network connectivity and remote management tools for heavy-duty industrial IoT application including manufacturing, utilities, oil & gas, metals & mining, retail, healthcare, transportation & logistics, smart city, Embb (Enhanced Mobile Broadband) and others automotive use cased which only require low latency and high reliability.

HIGHLIGHTS

1. Incredible Speed
2. High performance, Industrial-Grade Design
3. Low latency, increased capacity
4. Extensive Interfaces, Enabling Flexible Expansion
5. Cloud-Based Platform Management
6. Secure and Reliable Network

CLASSIFICATION APPLICATION
1. eMBB (enhanced Mobile Broadband)
2. URLLC (Ultra Reliable Low Latency Communications)
3. Massive IoT

SPEC
⋆5G NR Global bands, DL 2.5Gbps, UL900Mbps
⋆Dual-core 880MHz CPU
⋆4 GbE LAN, 1xRS232, 1xRS485, 4xIO
⋆Wi-Fi 802.11ac, Max speed 867Mbps
⋆IPsec/Openvpn/PPTP/L2TP/GRE
⋆GPS Optial
⋆Storage Optional
⋆Dimension: 132*112*44mm

Parameter Name	Parameter Value
Type	cellular wireless
Network	LTE 5G 4G LTE
Mounting	DIN rail mounted wall-mounted
Number of ports	4 ports
Other characteristics	firewall with VPN dual sim high-speed with I/O mobile broadband rugged
Applications	for IoT applications M2M industrial
