Compact linear actuators with absolute encoder for DC power supply

DR series

Features
Battery-free absolute sensor
No external sensors required
Compact and lightweight
EtherCAT, EtherNet/IP, Profinet, Modbus RTU

Frame size: 28 x 28 to 66 x 28.5 mm
Thrust: 20 - 40 N
Push force: 50 N
Max. speed: 40 - 100 mm/s
Max. Transport load: 0 - 4 kg
Options: Spindle protection, mounting flange, mounting foot

Parameter Name	Parameter Value
Movement	linear
Type	electric
Technology	stepper ball screw
Motor	DC
Applications	for process automation
Other characteristics	compact motorized integrated lightweight with flange with brake with sensor option
Stroke (mm)	30 - 30
Force (N)	40 - 40
Speed (mm/s)	40000 - 100000
