Application - Detection of high-gloss or polished surfaces
Detection of transparent objects
Special version - V-optics
Wash-Down design
Black-white error - < 10% up to 100 mm
Operating range, white 90% - 0.015 ... 0.15 m
Operating range, gray 18% - 0.015 ... 0.13 m
Operating range, black 6% - 0.015 ... 0.11 m
Operating range limit - 0.015 ... 0.15 m
Adjustment range - 20 ... 150 mm
Light source - LED, Red
Light spot size [at sensor distance] -
Protective circuit - Polarity reversal protection
Short circuit protected
Supply voltage UB - 10 ... 30 V, DC, Incl. residual ripple
Residual ripple - 0 ... 15 %, From UB
Open-circuit current - 0 ... 15 mA
Number of digital switching outputs - 2 Piece(s)
Switching element - Transistor, Push-pull
Switching principle - IO-Link / light switching (PNP)/dark switching (NPN)
Switching element - Transistor, Push-pull
Switching principle - Dark switching (PNP)/light switching (NPN)
Switching frequency - 1,000 Hz
Response time - 0.5 ms
Type - IO-Link
Specification - V1.1
Type of connection - Cable with connector
Cable length - 200 mm
Number of conductors - -wire
Thread size - M12
Material - Stainless steel
No. of pins - 4 -pin
Dimension (W x H x L) - 14 mm x 35.4 mm x 25 mm
Housing material - Stainless steel
Material of operational control - Plastic (POM Hostaform C9021, copolyester Tritan TX1001), non-diffusive
Housing roughness - Ra ≤ 0,8, Typical value for the stainless steel housing
Stainless steel housing - AISI 316L, DIN X2CrNiMo17132, W.No1.4404
Lens cover material - Plastic (PMMA+) with scratch-resistant Indium protective coating
Net weight - 59 g

Parameter Name	Parameter Value
Measured physical value	light
Applications	for safety edges
Mounting	through-hole
