Operating principle - Reference teach on background
Operating range - 0.05 ... 0.2 m
Adjustment range - 50 ... 200 mm
Light source - LED, Red
Protective circuit - Polarity reversal protection
Short circuit protected
Supply voltage UB - 12 ... 30 V, DC, Incl. residual ripple
Residual ripple - 0 ... 15 %, From UB
Open-circuit current - 0 ... 40 mA
Number of digital switching outputs - 1 Piece(s)
Switching element - Transistor, PNP
Switching principle - Dark switching
Switching frequency - 750 Hz, (Teach level 1: 500 Hz)
Response time - 0.66 ms
Type of connection - Connector
Thread size - M12
Material - PUR
No. of pins - 4 -pin
Dimension (W x H x L) - 15 mm x 42.7 mm x 30 mm
Housing material - Plastic
Plastic housing - ABS
Lens cover material - Plastic
Net weight - 22 g
Type of fastening - Through-hole mounting with M4 thread
Via optional mounting device
Compatibility of materials - ECOLAB
Operational controls - Teach button
Ambient temperature, operation - -10 ... 50 °C, Temperature compensation ±15°C
Degree of protection - IP 67
IP 69K
Protection class - III
Certifications - c UL US
Standards applied - IEC 60947-5-2

Parameter Name	Parameter Value
Measured physical value	light
Applications	for safety edges
Mounting	through-hole plastic housing
Other characteristics	IP67
