Hardware Specifications

1. Input voltage : DC 8V-30V , 0.08A
2. Linear scale settable resolution (mm) : 0.0001 , 0.0002 , 0.0005 , 0.001 , 0.002 , 0.005 , 0.01 , 0.02 , 0.05 , 0.1 , 0.2 , 0.5 , 1 , 5 , 10
3. Rotary encoder settable resolution (degrees) : 1 ~ 0.0001
4. Aluminum alloy body, excellent capability in EMS (2000V).

Software Functions

1. Zero setting.
2. 1/2 calculation, locate work piece center
3. mm/ inch conversion.
4. INC/ ABS conversion
5. Diameter/ Radius selection.
6. DIR: Setting the coordinate direction.
7. Error compensation:Linear compensation.
8. Instant power failure memory.
9. Self-diagnostic function for calculation error.
10. RS232 output.

Parameter Name	Parameter Value
Type	LCD
Applications	for metrology position
Other characteristics	RS-232
