Features
Aramid cord offers high tensile strength, high resistance to shock loads and minimum elongation
Specially designed bare fabric facilitates smooth clutching operation and high resistance to wear and tear
Able to withstand high levels of reverse flexing
Resistance to oil, heat and cracking
Temperature range: -18°C to +80°C

Constructional Details
1. Special insulation rubber compound offers superior adhesion
2. Specially treated aramid cords for high tensile strength
3. Fibre-loaded compression rubber base compound for enhanced power transmission
4. Special bare-back outer cover for the smooth clutching operation

Parameter Name	Parameter Value
Type	trapezoidal V
Material	rubber
Product applications	for heavy-duty applications agricultural for lawn-mowers
Sector	industrial
Other characteristics	high-performance for heavy loads high-power high-resistance wrapped maintenance-free oil-resistant heat-resistant aramide-corded
Length (mm)	445 - 9119
Width (mm)	9.7 - 12.7
Thickness	5.6 mm, 7.9 mm, 9.7 mm (0.22 in)
Temperature	Max.: 80 °C (176 °F)Min.: -18 °C (-0.4 °F)
