--Intel ®B75 chipset
--Support for Intel Ivy Bridge/Sandy Bridge LGA1155 package dual, quad core processor
--2*DDRIII 1066/1333MHz memory slot,max support 8GB memory
--1*VGA display interface
-- 3*audio output/input/Microphone
-- 2*COM 232 serial /4*SATAII
--8*USB 2.0 interface/2*RJ-45Gigabit Network Interface

processor -

Support for Intel Ivy Bridge/Sandy Bridge LGA1155 package dual, quad core processor

chipset -

Intel ®B75

memory -

2* DDR3 1066/1333MHz memory slot,max support 8G

graphics controller -

Chipset integrated graphics controller
Display interface: VGA

audio -

Realtek ALC622 audio decoder chip

network -

2*RTL8111E Gigabit Network

stroge -

4*SATAII

expansion -

4*PCI,ISA

USB -

8*USB 2.0

Front panel interface -

1*VGA display interface
2*RJ-45 Gigabit Network interface
1*PS/2 KM interface

Internal pin -

4*USB pin, support 8*USB
2*RS232 pin
1* Parallel pins
1* audio pin

Operating system -

Windows XP/7/2000, Linux

size -

338*122mm

Parameter Name	Parameter Value
Bus standard	ISA
Bus	serial, USB
Applications	industrial
