- block commutation
- for EC motors up to 50W

Features
• - sensorless *
• - speed controller
• - 1 analogue input speed controll 0-1V or high-ohm = Stop; 1-4,5V = Duty Cycle PWM
0-99%
• - 1 digital input speed controll 0 - 1,6 V or high-ohm = right; 3,9V - 5V = left
• - option start without external controller
• - option counter-clockwise rotation without external controller
• - overcurrent protection

Parameter Name	Parameter Value
AC/DC	DC
Motor type	EC
Other characteristics	integrated
Input/output	digital input
Input voltage	Min.: 9 VMax.: 30 V
Output voltage	24 V
Current (A)	2.65 - 2.65
