A custom engineered solution to satisfy all demands for quick and simple cabling added to a first-in-class performance to size ratio. Mack Tron motor with integrated drive is the ideal solution for decentralized application architectures.
Ultra compact for installation in limited space and discreet for enhanced machine design.
8 pole motors up to 400W
B.E.M.F. and current sine waveforms
Mack Serial Encoder, single or multiturn absolute
Bi-color LED status signals
SpeederOne.2 PC software interface
RS485 for setup and monitoring
Protection rating IP54 and IP65 on request
Automatic holding brake
Electromagnetic holding brake
Special flanges and shafts
STO Safe Torque Off
3 Digital inputs (programmable)

Parameter Name	Parameter Value
AC/DC	DC
Type	brushless
Voltage (V)	48 - 24
Protection class	IP54 IP65
Configuration	compact
Number of poles	8-pole
Other characteristics	programmable CANopen EtherCAT RS-485 integrated-drive custom performance
Power (W)	50 - 400
Torque (Nm)	0.15 - 1.2
Rotational speed (rpm)	1500 - 1500
