About
Umicore’s GASIR® infrared lenses have been developed for an easy fit with a wide range of camera cores. Our catalog lenses provide a cost-effective
solution for high-resolution thermal imaging and sensing applications.
This lens may be offered with other coating variants upon request. This high performance lens is optimised for minimum weight. Material choices allow a moderate temperature range with passive optical athermalisation.
This lens is compatible with 12 μm SXGA detectors and smaller.
Optical Properties
Product number (HEAR)
21048_100
Focal length
18.6 mm
F-number
f/1.0
Transmission (HEAR)
>91%
Focus range
4 m to infinity with refocus of 0.06 mm
Waveband
8 - 12 µm
Mechanical properties
Weight (HEAR)
111g
Interface thread
M34x0.5
Back focal length*
10.0 mm
value applicable with 0.725 mm Si window (not included)
Environmental properties
Sealing (HEAR)
IP67
Operating temperature
-40°C to +80°C
Storage temperature
-50°C to +107°C
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
infrared
|
| Technical applications |
thermal imaging
|
| Other characteristics |
high-resolution
|
| Focal length |
18.6 mm(0.73 in)
|
| Image circle |
19.7 mm(0.8 in)
|
