Image processing tools: Gray value, object -, edge - and positioning functions, pattern, stain, flaws - and bead detection
Analysis tools: Mathematical operations and measuring function
Vision manager software with intuitive user interface
1" CMOS, 5 MP image sensor
2-line, 8-segment LCD display with pushbuttons
5 x PNP/NPN, input/output
External trigger input
Connection for external lighting
Supports Ethernet protocol PROFINET, EtherNet/IP and Modbus/TCP)
Protection class IP20, IP67 with lens cover (sold separately)
C-mount lens (sold separately)

Country of origin - CN
Weight - 567 g

Technical Data
Function - Multifunctional
Resolution - 2592 x 2048
Output function - Input/output programmable, 5 × PNP/NPN optically decoupled
Communication protocol - EtherNet/IP, FTP, Modbus TCP, PCCC, PROFINET, RS232
Electrical connection - Connector, M12 × 1
Housing material - Metal, AL
Ambient temperature - 0…+50 °C

Parameter Name	Parameter Value
Applications	industrial communication
Technology	digital
Function	measuring image processing
Spectrum	infrared
Sensor	CMOS
Interface	Ethernet IP
Resolution level	UHD
Resolution	4 Mpx
Other characteristics	smart IP67 programmable
