Produce crystal clear, vibrant images with Teledyne Lumenera’s INFINITY microscopy cameras. Our user friendly HDMI, USB 3.0 and USB 2.0 cameras range in resolution from 1.4 to 32 megapixel and feature CMOS, CCD, High Definition (HD), low light CCD, large format, research-grade and pixel shifting technologies.

As one of the most respected digital camera manufacturers in the scientific market, we install thousands of INFINITY cameras each year into life science, clinical and industrial applications.

Trust Lumenera to provide high quality, scientific-grade cameras complete with feature rich software packages at the best price-to-performance ratio in the market.

Specifications
• Color CMOS sensor with 1/1.8” optical format
• 8.3 megapixel camera with fast frame rates of 96 fps at full resolution (3840 x 2160)
• Direct USB3 interface for fast image delivery and simplified connectivity
• Compact form factor
• Support for locking industrial micro USB on the back for power and control
• INFINITY ANALYZE microscopy software included with purchase. No annual license fees. (camera requires INFINITY ANALYZE .7.0.3 or higher)
• Software support for Windows and Mac, along with third-party plugins for MetaMorph and MicroManager
• Selectable 8 or 12-bit pixel data
• Recommended coupler: 0.5x - 0.63x

Parameter Name	Parameter Value
Applications	industrial for microscopes
Technology	digital
Function	image processing
Spectrum	full-color, monochrome
Sensor	CMOS, CCD
Interface	USB 3.0 USB 2.0 HDMI
Resolution level	HD, 3840 x 2160
Other characteristics	high-speed high-sensitivity megapixel low light fluorescence compact
