PRODUCT DETAIL

Wonder SSWEA Series 3 phase asynchronous induction motors are super premium efficiency motors with aluminum housing. The efficiency indicators comply with IE4.

Wonder electric motors with aluminum housing have outstanding advantages such as less weight, compact structure, splendent appearance, high efficiency, low noise, low vibration, easy maintenance, etc.

In addition, Wonder has realized reduced operating temperatures of our products. Redesigned to provide improved air flow through all motor frames keeping low operational temperatures and assuring reliability and extended lifetime, the aerodynamic concept of the fan cover increases effective airflow, thus minimizing losses due to the recirculation of air between fan and fan cover. The impeller was designed to provide a tough structure and to reduce noise level. Motor terminal box and eyebolts was repositioned to allow better airflow.

The optimized cooling system also contributes to cooler bearing temperature, extends relubrication intervals and provides longer bearing lifetime and lower noise level fulfilling the most demanding health & safety regulations.

Main Tech Specifications:

Frame Size: 80-180mm
Output Power: 0.75-22kW
Speed: 3000, 1500, 1000r/m
Poles: 2, 4, 6
Protection Class: IP55 or above
Insulation Class: F or above
Cooling Method: IC411/IC416

Industries:

Water Treatment
Textile
Air Handling
Chemical & Metallurgy
Aggregate & Cement­­
Food & Beverage & Pharmaceutical
Construction
Transportation

Parameter Name	Parameter Value
AC/DC	3-phase
Type	asynchronous
Protection class	IP55
Configuration	aluminum compact
Number of poles	2-pole 4-pole 6-pole
Applications	for water treatment applications for the textile industry for water pumps for hydraulic applications food for pumps blower for compressors for crane for wood-processing machines
Other characteristics	with gearbox low-voltage IE4 low-noise
Power (W)	750 - 22000
Rotational speed (rpm)	1000 - 1000
Diameter (mm)	314 - 698
