Programmable sensor interface for optical and magnetic position sensors
Linear gauges and incremental encoders
Linear scales
Features
PGA inputs to 500 kHz for differential and single-ended sensor signals
Selectable adaptation to voltage or current signals
Flexible pin assignment due to signal path multiplexers
Sine/Cosine signal conditioning for offset, amplitude and phase
Separate index signal conditioning
Short-circuit-proof and reverse polarity tolerant output drivers (1 Vpp to 100)
Stabilized output signal levels due to sensor control
Signal and system monitoring with configurable alarm output
Supply voltage monitoring with integrated switches for reversed-polarity-safe systems
Excessive temperature protection with sensor calibration
I2C multimaster interface
Supply from 4.3 to 5 V, operation within -25(-40) to +100 °C
With output multiplexer (not for SAFETY)
Verifyable chip release code
Version iC-MSB suitable for SAFETY applications
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Format |
IC
|
