・High Efficiency

Less sliding and greater efficiency compared to a worm gear. At the same output, there is less power consumption and greater cost effectiveness.

・Low Noise

Tsubaki’s know-how in gear motor processing technology ensures low noise and high reliability.

・Usability

The grease is already encapsulated so it’s ready to use. It can be installed in any direction.

Tap processing is standard on the output shaft edges. For the hollow type shaft, the torque arm and shaft edge cover are available as options.

・With inverter motor (0.1kW to 0.4kW only)

The inverter-compatible motor can be directly connected, and the dimensions are exactly the same as those of thestandard model. Even in the low frequency range (6 Hz and more), continuous operation at 100% constant torque is possible.

Equipped with a High Efficiency motor of 0.75kW or more has the same characteristics as those with inverter motor.

・Compact

Particular emphasis on the height dimension, this reducer is extremely short and compact.

Parameter Name	Parameter Value
Motor type	three-phase single-phase
Type	hypoid
Shaft orientation	right angle
Power (W)	100 - 500
Other characteristics	compact low-noise aluminum frame
