About
The hydraulic cylinder has a test pressure of 300 bar and a maximum working pressure of 200 bar. This tool has a working speed that can reach up to 0.5 m/s. It can work in an ambient temperature that ranges from -30°C to +90°C. It utilizes the mineral hydraulic oil for operation.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
hydraulic
|
| Configuration |
double-acting
|
| Other characteristics |
standard
|
| Stroke (mm) |
200 - 1500
|
| Speed (mm/s) |
500 - 500
|
