Short Description:
Series Model Step Angle Motor Length Rated Voltage Rated Current Phase Resistance Phase Inductance Holding Torque Detent Torque Rotor Torque Lead Wires Motor Weight ( °) (mm) (V) (A) (Ω) (mH) (N.cm) (N.cm Max) (g.c㎡) (NO.) (g) 8HS2402 1.8 28 4.6 0.2 23 8.2 1.4 0.2 2.5 4 50 8HS2406 1.8 28 1.92 0.6 3.2 0.9 1.4 0.2 2.5 4 50 8HS3402 1.8 33 5 0.2 25 8.4 1.8 0.3 3.2 4 70 8HS3406 1.8 33 3.9 0.6 4.5 1.7 1.8 0.3 2 4 70 8HS4406 1.8 40 3.48 0.6 5.5 1.8 3 0.5 4.5 4 80 8HS4408 1.8...

Step Accuracy---------------------------------±5%
Temperature Rise----------------------------80℃ Max.
Ambient Temperature Range---------- -20℃~+50℃
Insulation Resistance-----------100MΩ Min.50V DC
Dielectric Strength-----------------500V AC 1minute

Parameter Name	Parameter Value
AC/DC	two-phase
Type	hybrid stepper
Voltage (V)	5 - 5
Torque (Nm)	0.014 - 0.014 0.018 - 0.018 0.03 - 0.03
