Beside the standard program BAUSER offers you a range of individual special developments. Inform us about your requirements and ideas – we find a solution for you.
Our developing and production know-how is excellent. This was certified according ISO9001. That is why we can guarantee to our worldwide OEM customers high quality products in the shortest tim

Reset:
No
Counting range:
99999,99 h
Digits:
1,5 x 3,5 mm (with lens 4 mm), white on black, decimals black on white
Standard voltages:
115 or 230 V AC
Special voltages (at additional cost):
12, 24, 36 – 48 and 400 V AC
Voltage tolerance:
±10 %
Frequency:
50 or 60 Hz – (on request 50 and 60 Hz)
Current consumption:
Approx. 10 mA at rated voltage
Protection class:
DIN 40050, housing IP 65 (front)
terminals: IP 20 (Variant VBG 4) IP 00 (without VBG 4)
Testing voltage:
Winding and contact against GND 2500 V/50 Hz
Ambient temperature:
–30 °C to +80 °C
Fixing:
Via included retaining clip*, panel thickness up to 10 mm, or via integrated snap-in lugs, panel thickness up to 2 mm, whereas the cutout should be 45,2 + 0,3 x 45,2 + 0,3 mm
Connection:
Terminals or plugs, with or without protection against accidental contact
Approvals:
CE , optional UL and CSA
Operating indication
Yes
Weight:
Approx. 46 g

Parameter Name	Parameter Value
Type	hour
Display	analog
Technology	electromechanical
Protection level	IP65 IP20
Other characteristics	DIN rail
