■Dimensions (W x H x D): 120mmx100mmx40mm
■Programming on site with master key or with programming terminal
■Wiring: 2 max fils/100m between the controller and reader
■Power supply: 12/24 Vac or Vdc
■Control relay: NC / NO
■Adjustable timer from 1 to 99 seconds
■Removable connections
■Operating temperature: -20 ° C to +€0 3 C
Easy Door Receiver is an RF access control system for small residential
applications. It is an all-in-one product (controller and receiver) which has
been designed for 2 gates and can manage up to 2000 users.
The same product can be managed either away from its installation place
(remote management or so called Virtual Network Mode) or on site
(standalone mode).
For remote management, all you need is an internet connection for our web
software www.easydoorcontroller.com and our USB encoder. Then you
have to:
1-Notethe controller Ne of the installed product (written on top label)
2-Registeron www.easydoorcontroller.com
3-Programthe transmitters/keys using the encoder which records one or
several n° of allowed doors inside the transmitter.
To remotely delete permissions for a transmitter, you simply have to cancel
that transmitter on the website and program a new one instead. At the first
use of the new one on the controller, the old transmitter will be blocked
instantly.

Parameter Name	Parameter Value
Type	HF
Interface type	internet
