● Small dimension supports more suitable narrow aisles and more environments;
● Lighter weight makes lower power consumption and longer working time possible;
● Brake motor guarantees shorter urgent-braking distance to assure security in working environment;
● Combination of multiple schemes of obstacles avoidance gives device alarm with more sensitivity;
● Real-time status feedback and real-time platform control support overall dispatch;

Rotation Diameter
1180mm

Lifting Height
60mm

Ground Clearance Height
25mm

Lifting Pallet Dimensions
720×720mm

Lifting Method
Electric

Net Weight
200KG

Load Capacity
1000KG

Navigation
Visual (QR code)

Communication Mode
802.11b/g/n/ac

Drive
Differential Drive

Parameter Name	Parameter Value
Applications	handling for warehouse for loading
Specifications	electric
Load (kg)	0 - 3000
