_ TAILOR MADE MACHINE: All below features can be amended according to your need


THIS APPLICATION: Parts transfer in the automotive field on 2 floors (AGVs go in an elevator)

_ Custom made frame: 2200 X 1850 x 670 mm

_ Typical load around 3000 kg and 3600 kg [Typically: 3000 to 500 000 kg or more]

_ Interface with floor: Wheels [wheels / rail wheels / air cushions / combination]

_ Lifting capacity: 50 mm [more if needed]

_ Interface with the payload: Specific pallet

_ Movement: Omnidirectional (drive in all directions)
[Omnidirectional, rotation on spot, diagonal, etc. - More option available]

_ Energy / autonomy: Battery pack (capacity) sized to your project

_ Safety: Safety scanner and others [fail/safe safety features: if needed]

_ Automatic solution and manual: AGV and tethered, wired remote control unit

_ Guidance mode: According to your need

_ Specific: Very high reliability level

_ Easily accessible compartments for servicing and/or maintenance

_ CE Certification, other continents


_ Market: Automotive
_ Application: Supply parts on an automotive production line

_ Environment: Standard workshop
[Possible to have specific requirements like: ATEX, pyrotechnics, clean rooms, withstand fire, radiations, etc., Automatic battery switch: Since one battery is in use, a second pack is getting loaded. When battery level is too low, the AGV gets the other pack on board automatically]

_ Potential Markets
Railways, Aeronautics, Energy, Production and assembly, Metallurgy (steel and cables), Paper and cardboard, Logistics, Machining, Defence, Automotive, Industries, Plastics, Non-food, food, etc.

Parameter Name	Parameter Value
Applications	handling transfer for pallets for the automobile industry
Specifications	electric for heavy loads omnidirectional multidirectional
Load (kg)	0 - 3600
