About
The GaugerGPS is appointed with a heavy duty GPS terminal complete with RS485 output solid GPS, and it arrives in a compact sealed box. This unit is embedded with a GPS receiver with interior antenna, which makes this transceiver and power supply. The user is a four cable wire that is open, two wires for power and two wires for data. The specificaitons of this GPS receiver include -165dB signal level detection, 65 channels, -165dB. Position accuracy, 60 nSec time accuracy, 1 Sec hot startup, 30 Sec cold startup, 1 message per 3 Sec NMEA-0183 GPGLL location and time, RS485 interface, and 4800 (8/N/1 baud rate. The communication protocols is user configurable according to user needs.
The embedded specifications of the GaugerGPS includes 7 to 36 VDC input voltage, p to 20ma at 24VDC. input current, 2m (6.5') regular cable length, which can be stretched to 50m (160'), 52 X 40 X 26 mm package measurements and IP68 (NEMA 6) sealing rate.
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
GPS
|
| Applications |
for radio remote control
|
| Other characteristics |
with integrated antenna
|
