About
The displacement values are dependent on the RPM and power output. Careful alignment of the shafts increases the service life of the coupling.
max. misalignment axial: ± 3,4 mm
max. misalignment radial: ± 0,5 mm
max. misalignment angular: ± 1,2
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Type |
flexible
|
| Product applications |
shafts
|
| Other characteristics |
torque
|
| Installation system |
sleeve and shear pin
|
| Torque (Nm) |
1.28 - 33.5
|
| Rotational speed (rpm) |
4000 - 14000
|
