Material flange:steel
Material spider:NBR
Working temperature:from -40 to +100 °C
Product description:ESSEX coupling are very inexpensive, elastic coupling for simple applications. In a limited area, they compensate shaft offsets and steam peak loads such as oscillations.
Version:flexible couplings
On request:Coupling part are deliverable with bores and groove. Cam ring in other materials and hardnesses
Characteristics:simple constructions, puncture-proof, insensitive against humidity, fats and oils and against none aromatic solvents

Parameter Name	Parameter Value
Type	flexible
Product applications	for shafts
Installation system	flange
Torque (Nm)	3.51 - 25.8
Rotational speed (rpm)	9000 - 18000
