Fixed-focus camera lens MH-S series

in Lenses

Fixed-focus camera lens MH-S series
in Lenses

Fixed-focus camera lens MH-S series

in Lenses

About


● Support up to 1/1.8" camera sensors;
● 9 models, focal length covering from 4mm to 75mm;
● High resolution for 3MP camera in full of view;
● Design for close working distance,more suitable for industrial vision inspection scenarios;
● Small size structure suitable for system integration and installation;
● Stable sharpness quality when temperature varies from -20℃~50℃;

Aperture
F2.0 - C

Image Sensor Size
Ф9mm(1/1.8'')

Focus Range
0.1m to infinite

Optical Distortion
-4.2%

TV Distortion
-0.66%

Field of View
94.0°x82.9°x66.5° (9mmx7.2mmx5.3mm)

Relative Illumination
43.3% (F2.0); 69% (F4.0)

CRA(Chief Ray Angle)
12°

Spectral Range
420nm~1150nm

Spectral Transmission
T>79%



PARAMETERS

Parameter Name Parameter Value
Type
fixed-focus
Technical applications
  • machine vision
  • inspection
Other characteristics
  • high-resolution
  • low-distortion
Focal length
Min.: 4 mm(0.16 in)Max.: 75 mm(2.95 in)
