Functions - Alignment mode
AutoConfig
AutoControl
AutoReflAct
Code fragment technology
Heating
LED indicator
Reference code comparison
Code types, readable - 2/5 Interleaved
Codabar
Code 39
Code 93
Code 128
EAN 8/13
EAN 128
EAN Addendum
GS1 Databar Expanded
GS1 Databar Limited
GS1 Databar Omnidirectional
UPC
Scanning rate, typical - 1,000 scans/s
Bar codes per reading gate, max. number - 64 Piece(s)
Reading distance - 400 ... 900 mm
Light source - Laser, Blue
Wavelength - 405 nm
Laser class - 2, IEC/EN 60825-1:2014
Modulus size - 0.25 ... 0.35 mm
Reading method - Line scanner
Beam deflection - Via rotating polygon wheel
Light beam exit - Front
Supply voltage UB - 10 ... 30 V, DC
Power consumption, max. - 14 W
Number of inputs/outputs selectable - 4 Piece(s)
Type - PROFINET
Function - Process
Conformance class - B
Protocol - PROFINET RT
Switch functionality - Integrated
Type - USB
Function - Configuration via software
Service
Number of connections - 5 Piece(s)
Function - Service interface
Type of connection - USB
Connector type - USB 2.0 Standard-A
Function - Signal IN
Signal OUT
Type of connection - Connector
Thread size - M12
Type - Female
Material - Metal
No. of pins - 5 -pin
Encoding - A-coded
Function - PWR / SW IN / OUT
Type of connection - Connector
Thread size - M12
Type - Male
Material - Metal
No. of pins - 5 -pin
Encoding - A-coded
Function - BUS IN
Type of connection - Connector
Thread size - M12
Type - Female
Material - Metal
No. of pins - 4 -pin
Encoding - D-coded
Function - BUS OUT
Type of connection - Connector

Parameter Name	Parameter Value
Portability	fixed
Number of axes	1D
Other characteristics	USB industrial laser
