GLsun SFP-10G-SR Small Form Factor Pluggable (SFP+) transceivers are compatible with SFF-8431, SFF-8432, and support 10G Ethernet SR and 10G Fiber Channel. This 10G SFP+ SR Transceiver is designed for use in 10G-Gigabit multi-rate links up to 300m of OM3. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472.

features

· Duplex LC connector

· Hot-pluggable SFP footprint

· Uncooled 850nm VCSEL laser

· RoHS compliant and Lead Free

· Distance up to 300m on 50/125um MMF

· Metal enclosure for lower EMI

· Low power dissipation <1.0W

· Commercial and industrial operating temperature optional

· SFP MSA SFF-8472 SFF-8431 SFF-8432 Compliant


· 10GBASE-SR/SW

· 10G Fibre Channel

Form Factor：SFP+

Max Data Rate：10Gbps

Wavelength：850nm

Max Cable Distance：300m on 50/125um MMF

Connector：Duplex LC

Parameter Name	Parameter Value
Network	Ethernet
Other characteristics	SFP
