DESCRIPTION
The new International Standards IEC61850 defines a communication protocol oriented to the supervision, control and protection for the generation systems, transmission and distribution of electricity.
These are some of the main characteristics:
- Just one protocol for all system levels, from the field level to the supervision level.
- A high standardization and an accurate and clear defnition of the functions and of the services involved.
- The use of the Ethernet network as transmission medium, while still maintaining the ability to evolve towards other means.
Technical data
Ethernet interface IEEE802.3, IEEE802.3u
protocol IEC61850 Ed. 1-2 + HTTP
speed 10/100 Mbps
connection 1 x RJ-45
serial interface RS 485 Master
connection morsetti a vite / terminal blocks
protocol ModBus RTU
stop bits 1, 2
parity bits odd, even, none
baud rate 9600, 19200, 38400 bps
signals RS485: Data+, Dataprotezione ESD ESD protection 15 kV
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Bus |
Ethernet, Modbus
|
| Other characteristics |
industrial
|
