Serial converter for TCP/IP protocols

MDB-E works independently of the protocol by connecting all the protocols based on TCP / IP with the serial ones in a completely transparent way. This simplifies the configuration and installation of the bridge.
Serial RS232/RS485 – Ethernet converter

MDB-E is a bidirectional converter between the Ethernet communication channel and RS232 / RS485 serial channels. Therefore, it allows all devices equipped with a serial port to communicate with software or cards on Ethernet communication. MDB-E also acts as an RS232 / RS485 converter.Thanks to the NFC interface (Near Field Communication) the configuration is very simple and practical. A dedicated APP allows you to read, modify and set all device parameters. The galvanic isolation of the serial ports ensures protection for all connected instruments and is a guarantee of isolation from the rest of the system.

This Ethernet – Serial converter has been specifically designed for industrial environments, equipped with 10-30Vdc extended range power supply and with protection on the serial port thanks to galvanic isolation.
It is easily programmable thanks to a dedicated APP and the integrated NFC interface, they do not require any additional software for configuration.

MDB-E functions are available in three versions:

Ethernet – RS485
Ethernet – RS232
RS232 – RS485
Ideal as a converter for ModBus protocol.

Parameter Name	Parameter Value
Type	protocol
Bus	Ethernet, serial, RS232
Other characteristics	galvanic programmable
