Specifications:
Ports: 1xEthernet; 1xRS485
Ethernet Connector RJ45
RS485 Connector 3way 5mm terminal block
Data Rates Ethernet: 10/100 Base-T Autosensing
Data Rates Serial Up to 115200 bps
Power supply 8…24V AC; 12…35V DC
Operating temperature -40°C/+85°C (-40°F/+185°F)
Dimensions 120x23x107 mm(DxWxH)
Weight 200g approx
Mechanical fixing DIN Rail montage
Software SW67038
ORDER CODE: HD67038-5-A1

Parameter Name	Parameter Value
Bus	Ethernet, RS-485
Other characteristics	DIN rail
