Features:
4-pole rotor with plastic-bonded magnets NeFeB
Threefold winding connected in delta
Internal Hall sensors for rotor position detection offest by 120°
Closed aluminium housing with aluminium bearing flanges
Direction of rotation CW / CCW
Multiple combination possibilities with gears, encoders, and brakes

Parameter Name	Parameter Value
AC/DC	DC
Type	EC
Voltage (V)	24 - 24
Number of poles	4-pole
Power (W)	10 - 10 15 - 15
Intensity (A)	0.91 - 1.08
Torque (Nm)	0.025 - 0.025 0.04 - 0.04
Rotational speed (rpm)	3600 - 3600
Diameter (mm)	35 - 35
Operating temperature (°C)	-30 - 40
