Functions - Activation/deactivation of function modules
Diagnostics data transfer via AS-Interface
Dynamic contactor monitoring (EDM), selectable
Error unlocking via AS-Interface
Monitoring modules with contact-simultaneity monitoring
Programmable logic operators, system statuses
STOP 0 / STOP 1
Service button for manual error unlocking and automatic device swap-out of the safe AS-i slaves
Start/restart interlock (RES), selectable
Status LED display for AS-Interface communication, OSSD, start/restart interlock, protective mode, errors
Support of AS-Interface A/B technology
System signal output
Number of configurable function modules - 32 Piece(s)
Number of programmable logic operators, OR (inputs) - 2 Piece(s)
Muting function - No
SIL - 3, IEC 61508
SILCL - 3, IEC/EN 62061
Performance Level (PL) - e, EN ISO 13849-1
PFHD - 9.1E-09 per hour
Mission time - 20 years, EN ISO 13849-1
Category - 4, EN ISO 13849
STOP category - 0 and 1, IEC/EN 60204-1
B10d at DC13 (inductive load) - 10,000,000 number of cycles, (I < 2 A, 24 V)
B10d at AC15 (inductive load) - 100,000 number of cycles, (2 A, 230 V), 250,000 (1 A, 230 V), 540,000 (0.5 A, 230 V)
Number of safety monitors per AS-Interface network - 4 Piece(s)
Number of safety monitors, additional text - With maximum 31 integrated AS-Interface slaves
Protective circuit - Polarity reversal protection
Short circuit protected
Supply voltage UB - 24 V, DC, -15 ... 15 %
Supply voltage UB - V
Current consumption, max. - 150 mA, Without external load
Current consumption from AS-i circuit - 45 mA
Overvoltage category - III, For rated operating voltage of 300 V AC in accordance with VDE 0110 part 1
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Mounting |
DIN rail-mounted
|
