100 times/sec. High speed sampling.
High display resolution to 16,000 counts.
Up to 1 million counts of A/D resolution.
Monitor & control weighing and batching with external or internal resolution.
Fuzzy and Automatic Free Fall Compensation (AFFC) for consistently accurate batching results.
Enter control set points through front keys or remotely though external thumb wheels.
Automatic weight and/or count accumulation.
Sub display provides feedback on all set points & simplifies calibration.
Supplementary flow function assures accurate performance on each batch.
A host of communications capabilities:
RS-232C, RS-422/485, BCD, analog output and standard 4-20mA Current Loop.
Connect up to 10 AD-4401's with A&D's RS-422/485.
Compact DIN size housing speeds installation & reduces space.
Digital Span Calibration enhances technical support and difficult installations.
Splash proof front panel and keys (IP-65).
High sensitivity 0.3(µV/d for more accurate measurements.
Automatic batching and customer programming capability.
Bright, clear fluorescent displays.
Hold and peak hold functions.
User programmed timer settings and alarms.
Improve operational safety & performance.
Weigh-in and Loss-in-Weight batching.

Parameter Name	Parameter Value
Type	digital
Other characteristics	panel-mount high-speed benchtop
Applications	for accurate weighing for filling machines for packaging machines
