Main features:
1) Dual and three digits display
2) Single input: K/J/E/N/PT100
3) Control output: Relay/ SSR logic SPDT relay 5A@250VAC, 6a@ 125VAC relay +12VDC logic driving SSR, 35mA max. load
4) One or two configurable relay alarms
5) Heating/

Specification
1) Dural three digits display
2) Single input: K/J/E/N/PT100
3) Control output: Relay/ SSR logic
SPDT relay 5A@250VAC, 6a@ 125VAC relay
+12VDC logic driving SSR, 35mA max. load
4) One or two configurable relay alarms

5) Heating/ cooling control selectable
6) Auto-tunning
7) Control method: PID, ON/ OFF
8) Power in 100 to 240VAC
9) Operating enviroment
Temperature 0 to 50 °C
Rlative humidity 30% to 85%(non-condensing)
10) Plug-in plastic housing

Specification:
1) Power supply voltage:110~ 220VAC
2) Operating frequency:50-60 Hz
3) Power consumption:3VA
4) Measuring accuracy:±0.5%F.S. Or ± 1 digit max.
5) Cold junction:±2 °C
6) Sampling cycle:2 times/second
7) Recommended fuse:T2A, 250VAC, time-lag, low-breaking capacity
8) Weight:Approx. 300g
9) Available size:48*48*110mm; 48*96*110mm; 72*72*110mm;
96*48*110mm; 96*96*110mm

Parameter Name	Parameter Value
Display	digital
Type	PID
Use	heating cooling
Other characteristics	configurable auto-tuning
Maximum temperature (°C)	0 - 50
