Up to Four Temperature Zones P, PI, PD, PID, Autotune
Open-loop Control
Output: PWM 1KHz, duty cycle resolution=1000 steps Hot / Cold direction
(logic 0/1)
Input: Thermocouple: J, K, T; RTD: PT100 (DIN); Thermistor: 2252 ohm or 10K ohm
Resolution: 0.1°C
Communications: USB, interface cable included
H-Bridge: Use with one or multiple HA-5300 700 watts H-Bridge Amplifier
Software: tecaLOG Windows based real time plotting, logging, programming
and tuning software
LabView: Write your own LabView program (VI examples available)
Includes: wiring harness, USB cable and driver, tecaLOG software
Ingress Protection: IP65 front panel (applies to panel mount only)

Parameter Name	Parameter Value
Display	digital
Type	PID
Protection level	IP65
Maximum temperature (°C)	0 - 50
