PROFINET device, EtherNet/IP device or Modbus TCP slave
Integrated Ethernet switch
Supports 10 Mbps/100 Mbps
2 × M12, 4-pin, D-coded, Ethernet fieldbus connection
PROFINET S2 system redundancy
Glass fiber reinforced housing
Shock and vibration tested
Fully potted module electronics
Protection classes IP65, IP67, IP69K
M12, 5-pin, L-coded male connector for power supply
Galvanically isolated voltage groups support passive safety
Input diagnostics per port
Max. 2 A per output
Output diagnostics per channel
Two freely selectable digital channels per port
Programmable ARGEE

Country of origin - DE
Weight - 572 g

Technical Data
Network protocol - Modbus TCP, EtherNet/IP, PROFINET
Signal type - Digital input, Digital input/output, Digital output
Connection technology signal - M12
Device type - I/O Module, Compact station, Field Logic Controller (ARGEE)
Fieldbus transmission rate - 10/100 Mbps
Fieldbus connection technology - 2 × M12, 4-pin, D-coded
Ambient temperature - -40…+70 °C

Parameter Name	Parameter Value
Signal type	digital
Bus	Ethernet, EtherNet/IP, Fieldbus, Modbus, ProfiNet, fieldbus
Type	network
Applications	voltage temperature
Mounting	integrated
Other characteristics	compact configurable IP67 IP65 universal
