About
Glass fiber reinforced housing
Shock and vibration tested
Fully potted module electronics
Protection classes IP65, IP67, IP69K
M12, 5-pin, L-coded male connector for power supply
Galvanically isolated voltage groups support passive safety
ATEX Zone 2/22
M12 ports for IO-Link master, 5-pin
IO-Link master port class A and port class B
IO-Link Protocol 1.1
Country of origin - DE
Weight - 567 g
Technical Data
Network protocol - EtherCAT
Signal type - IO-Link, Digital output, Digital input/output, Digital input
Connection technology signal - M12
Device type - I/O Module, Compact station
Fieldbus connection technology - 2 × M12, 4-pin, D-coded
Ambient temperature - -40…+70 °C
PARAMETERS
| Parameter Name | Parameter Value |
|---|---|
| Signal type |
digital
|
| Bus |
Fieldbus, IO-Link
|
| Type |
network
|
| Applications |
temperature
|
| Other characteristics |
|
