General characteristics
2 inputs (electrically isolated from the backplane bus)
24 VDC input voltage
Can accommodate two-wire proximity sensors
2 outputs (electrically isolated from the backplane bus)
24 VDC output voltage
Output current of 500 mA per channel
Outputs work with solenoid valves, contactors, small motors
A blue LED indicates the modules operating status
Green LEDs (one for each input) indicate the inputs and outputs states

Parameter Name	Parameter Value
Signal type	digital
Bus	CAN
Applications	current
Mounting	DIN rail
