Host Interface Ethernet
# of Ports 4/4
Brand/Family eI/O
Digital I/O Isolated Inputs, Form C Relay Outputs
RoHS Yes
Number of Inputs/Outputs 4 Inputs, 4 Outputs
Power Requirement 9-30 VDC @ 5W
Input Range 5-30 VDC
Input Isolation 2500 VAC RMS, 3500 VDC
Input Impedance 6.2 K Ohms (in series)
Output Power DC 240W, AC 300 VA
Contact Voltage 60VDC max., 200VAC max., (5VDC min.)
Contact Current AC 6A max.
Contact Current DC 30 VDC @ 700mA max., (100mA min.)
Contact Operate Time 10ms max.
Contact Release Time 5ms max.
Field Wiring 16-30 AWG
Operating Temperature 0 - +70C
Storage Temperature -50 - +105C

Parameter Name	Parameter Value
Signal type	digital
Bus	Ethernet
Number of inputs/outputs	4-I
