The original FAULHABER brushless DC servomotors. These ironless slotless motors are built for use in highly challenging areas of application and environmental conditions from the vacuum of space to medical device technology. They are precise, have extremely long operational lifetimes, and are highly reliable. They are available with a wide variety of complementary products such as high resolution encoders and precision gearheads. For maximum integration and reduction of size the standard digital hall sensors in the motors can be replaced with optional analog (linear) hall sensors which can eliminate the need for an encoder in most applications.

ADVANTAGES
- High density ironless system FAULHABER winding
- Digital or analog hall sensors available
- Extremely smooth speed control
- Sensitive positioning control

2 Pole Technology, High Speed,
for Autoclave Sterilisation

Nominal voltage:24 V
Torque up to (max.):13,7 mNm
No-load speed:44.300 min⁻¹
Stall torque:309 mNm
Diameter:20 mm
Length:57 mm

Parameter Name	Parameter Value
AC/DC	DC
Type	brushless
Voltage (V)	24 - 24
Configuration	slotless ironless
Power (W)	0 - 282
Torque (Nm)	0.0137 - 0.0137
Rotational speed (rpm)	44300 - 44300
Diameter (mm)	20 - 20
