For simple positioning applications with reduced requirements: the long-life stepper motor series with two-phase hybrid technology.

• Small increment and high driving torques thanks to 2-phase hybrid technology
• Optimized connection technology
• Four sizes with flange sizes 28, 42, 57 and 87
• 28 stock types
• With incremental encoder for closed loop operation
• Degree of protection IP40 (motor shaft), IP54 (sizes 42, 27, 87: motor housing and plug connection), IP65 (size 28: motor housing and plug connection)
• Available with holding brake

Parameter Name	Parameter Value
AC/DC	DC
Type	stepper
Voltage (V)	48 - 48
Protection class	IP54 IP65 IP40
Configuration	with brake
Applications	with built-in encoder
Power (W)	500 - 500
Intensity (A)	1.4 - 1.8
Torque (Nm)	0.3 - 6.5
Rotational speed (rpm)	430 - 6000
Operating temperature (°C)	-10 - 50
