Motors are available in 12, 24, 90, or 180 volts. Power range from 1/18 HP to 1/3 HP.

Armatures: Dynamically balanced
Commutators: Tang-type, diamond turned
Varnishing: Class H polyester trickle varnishing
Magnets: Highest grade ceramic
Finish: Gloss black powder coat

Brushes: Oversized with integral shunts Replaceable
Bearings: Double shielded ball
Shafts: Carbon steel
Casting: Zinc alloy
Mounting: Base and face
Insulation: Class F

Stock:DNS
Input Watts:17
CE:No
CSA:No
ROHS:Yes
CuRus:No
IP Rating:IP43
Insulation Class:F3
Duty Cycle:Continuous

Parameter Name	Parameter Value
AC/DC	DC
Type	brushed
Voltage (V)	24 - 12
Configuration	permanent magnet compact
Power (W)	14 - 14 17 - 17 28 - 28 37 - 37
Torque (Nm)	0.05 - 0.05 0.09 - 0.09 0.14 - 0.14 0.2 - 0.2
Rotational speed (rpm)	1800 - 1800
