Stable and Efficient, Maintenance Convenient

Ultra-thin design Fuselage

Extreme-optimized Planetary Reducer

Multi-functional small Fuselage weight 605g



Strong Power

Highly Integrated

Crossed Roller Bearing

Temperature, Position Sensor

Low Copper Consumption Coil

Instant Burst of Power
It can be adapted to a variety of large-load machinery and equipment such as foot robots, with greater torque and more stability. The output maximum torque is 33.5N.m,
which easily achieves a powerful instantaneous explosive force, and the maximum joint speed of 21rad/s makes the instantaneous speed beyond imagination.

The electronic wire adopts dip paint technology to better dissipate heat from the motor temperature.

The winding of a single strand of copper wire reduces copper wear and reduces the current interference between copper wires while making the motor more beautiful

The iron core has electrophoresis and high-temperature coating process that can pass the 48 hours salt spray test with the superior rust resistance and pressure resistance.

The imported 0.2 mm silicon steel sheet material is selected to reduce iron consumption.

Parameter Name	Parameter Value
AC/DC	DC
Type	asynchronous
Voltage (V)	24 - 36
Torque (Nm)	33.5 - 33.5
