High load resistance
Wide generality
Shock resistance
High torque
Low noise

Long life:

1.The gear is made of high-strength alloy steel and has been processed by a special heat treatment, ensure high safety
2. The reducer adopts high precision ball bearing to ensure high reliability of operation.
3.The reduction box is filled with advanced nano anti-wear grease to ensure good lubrication of the gear bearing

Low noise:
1.Adopt super high precision hobbing machine, gear processing accuracy up to 6 level or more.
2.The housing processed by high precision machining center, so that the position degree and concentricity of each bearing hole are strictly guaranteed at IT6 level
3.The lubricating grease in the reducer box has the function of wear resistance and noise reduction to further improve the noise level of the reducer.

High efficiency, low temperature rise
1.The optimized electromagnetic system ensures high efficiency and low temperature.
2.Silicon steel sheet adopts precision one - piece stamping technology, high precision and small loss.
3.The internal gears and oil seals are optimized to ensure low friction loss.

A Variety Models Complete
1.Motor frame size 60#-100#
3.Various models: YS YT YB YF YR and DC motor fit standard, right Angle solid shaft, right Angle hollow shaft, eared type reducer.
4. Powerful panel governor, digital display governor, multi-function governor and inverter to achieve speed.

Parameter Name	Parameter Value
Motor type	DC
Type	worm bevel
Shaft orientation	right angle
Shaft configuration	solid-shaft
Power (W)	100 - 500 10 - 50 50 - 100 0 - 10
Voltage (V)	220 - 110
Torque (Nm)	1 - 5 0.5 - 1 0.2 - 0.5 0.1 - 0.2
Performance	high-torque high-efficiency low-noise high load capacity
Product applications	industrial for automation for medical equipment for the food industry for conveyors for machines for the packaging industry for the chemical industry for packaging
Other characteristics	micro
Gear ratio (unit)	3 - 200
