Detailed Product Description
Z Series Cylindrical Gear Reducer

Cyclinder Gearbox Reducer Summary:
This product is cylindrical gear hard surface speed reducer as Chinese standard JB/T8853‐2001.It is widely
applied to the fields of metallurgy, mines, hoisting, transportation, cement, architecture, chemical, textile, printing and
dyeing, pharmaceutical, etc.
The suitable scope of speed reducer is as follows:
1.The rotation of high speed shaft should not be more than 1500rpm;
2.The circumferential velocity of gear transmission should not be more than 20,/sec;
3.The temperature of work environment should be ‐40‐45℃. If it below 0℃, before start, the lubricating oil should be
pre‐heated to above 0℃. This speed reducer can be run at clockwise and counterclockwise direction.
Characteristics
1.The gear is made of high strength low carbon alloy steel through carburization and quenching. The hardness of tooth
surface may reach to HRC58‐62. All gear adapts NC tooth grinding process, high in accuracy and good in contact
performance；
2.Highly transmission efficiency: single stage, more than 96.5%; double‐stage, more than 93%; three‐stage, more 90%;
3.Smooth and stable in run, low noise;
4.Compact, light, long life, high bearing capacity;.Easy to disassemble, inspect and assemble.

Parameter Name	Parameter Value
Type	cylindrical
Number of stages	single-stage
Performance	high-efficiency
Applications	transmission
Other characteristics	compact
Rotational speed (rpm)	1500 - 1500
