The BathyCorrometer® Pro’ Mk7 is the latest generation of the tried-and-tested, industry-standard BathyCorrometer® which has provided reliable service for subsea corrosion surveys since 1971.

Renowned for its rugged, dependable construction; the BathyCorrometer® has built a reputation for reliability and its ability to handle harsh environments whilst taking accurate measurements. The latest version of the industry-standard BathyCorrometer® brings a host of developments, designed to make measurement of simpler than ever and enhance the BathyCorrometer’s reliability even further.

Available options:
BathyCorrometer® Pro' Mk7 Basic kit
BathyCorrometer® Pro' Mk7 Standard kit
BathyCorrometer® Pro' Mk7 Complete kit
BathyCorrometer® Pro' Mk7 with long reach flexible probes

Features:
High-visibility LCD display for improved clarity
Latest surface technology electronics
Depth of operation: up to 350 metres
Facility for remote monitoring via Surface Display Unit Pro’
Proven, rugged construction
Single-handed and light
Robust and inert housing
Supplied with calibration certificate

Technical Specifications:
Display: 0.001 to -1.999v 3½ digit high visibility backlit LCD
Accuracy: 0.05% typical, instrument calibration accuracy +/- 1mV +/- 1 count
Battery charger: 14hr standard 110-230V AC
Input impedance: 1M Ohm
Operating temperature range 0 to 30°C, temperature stability 100ppm/°C
Operating time on full charge: 100hr +
Reference electrode: silver/silver chloride
Multi-function socket
Weight (unit only): in air 2.5Kg, in water 0.85Kg
Dimensions (unit only): 10cm x 27.5cm
Dimensions (carrying case): 38cm x 49cm x 19cm
Packed weight (Probe Kit): 9.5Kg

Parameter Name	Parameter Value
Type	corrosion
Applications	measurement marine for ships water device for storage tanks for coating for wind turbine for pipelines pipe for coastal areas for paints and coatings subsea
Domain	for the metallurgical industry for the mining industry
Configuration	portable mobile compact
Other characteristics	real-time continuous digital
