Features:
1. Specialized Desinged for non-stable-status machines, like wind turbines, etc.
2. 16 vibration channels, 2 processing information channels and 2 tacho channels, all channel sychronous acquisition, full time sampling
3. 24bit A/D converter
4. Fmax: 40KhZ
5. 12800 Lines
6. IP65 protection grade
7. Communication diversity: Ethernet, CAN, 485, etc
8. Compatible with voltage and current signal, provide 24V@4mA constant current source for IEPE accelerometers
9. Tacho channel is compatible with photoelectric sensor, eddly current type sensor, and hall sensor

Technical parameters:
1. Channels: 8 or 16 channels selectable
2. Input impedance: 220K
3. Accelerometer maximal value: 80g, 200mm/s, 10mm, 100mv/g sensor
4. Sensor drive current: 4mA@24V, for IEPE type accelerometer
5. A/D conversion: 24 bit delta-sigma ADC
6. Frequency range: 100Hz-40KHz
7. Signal range: +/-10V
8. Precision: 1% (0.1dB)
9. Frequency response: 0.2dB, 10-5KHz, 0.5dB, 3Hz-20kHz
10. Window: Hanning, Rectangle window
11. Continous acquisition: 4M bytes/CH
12.Lines: 400, 800, 1600, 3200, 6400, 12800
13. Time domain sampling: 1024, 2048,4096, 8192, 16384, 32768
14. Averaging type: Linearity, peak hold
15. Averaging times: 1, 2, 4, 8, 16, 32, 64
16. Storage: 1G Bytes
17. Wired Ethernet: TCP/IP, 10/100baseT, Optical (optional)
18.Communication: RS232, RS485, CANbus

Certification: CE, EX, GL

Website: www.ronds.com

Parameter Name	Parameter Value
Type	condition
Applications	turbine for rotary kiln measurement for machines for process control for remote control chemical gas alarm for bearings for wind turbine diagnostic for natural gas bearing
Other characteristics	continuous
